| Series |
521 |
| Status |
Active |
| Lens Size (mm) |
3.0 |
| Lens Shape |
Round |
| Output |
Single Color |
| Emitted Color |
Green |
| Peak Wavelength (nm) COLOR 1 |
565 |
| Intensity (mcd) COLOR 1 Typ |
12 |
| Forward Voltage (vdc) - Typ |
2.1 |
| Forward Voltage (vdc) - Max |
2.8 |
| Viewing Angle |
60 |
| Continuous Forward Current (mA) |
30 |
| Peak Forward Current (mA) |
120 |
| Reverse Voltage (V) |
5 |
| Certifications |
RoHS |
| Lens Color |
Tinted, Diffused |
| Test Current |
10 mA Int / 20 mA Voltage |
| Power Dissipation (mW) COLOR 1 |
120 |
| Derating mA/°C |
0.4 FROM 50°C |
| Operating Temperature |
-55°C to +100°C (-67°F to +212°F) |
| Storage Temperature |
-55°C to +100°C (-67°F to +212°F) |
