| Series |
623 |
| Certifications |
RoHS, IK10, IP66, IP67, NEMA 4X |
| Status |
Active |
| Mounting Hole Size |
1.18" (30.0mm) |
| Output |
Single Color |
| Emitted Color |
Red |
| LED Position |
Protruding |
| Lens Style |
Flat |
| Lens Color |
Tinted, Diffused |
| Voltage |
6 VDC |
| Resistor |
Internal Resistor Included |
| Mounting Method |
Nut/Washer |
| Max Panel Thickness |
.394" (10.0mm) |
| Mounting Torque |
7.01 |
| Mounting Torque Unit of Measure |
lb-ft |
| Typical Current (mA) |
15 |
| Typical Intensity (mcd) |
200 |
| Termination |
Screw Terminals |
| Termination Finish |
Stainless Steel |
| Housing Material |
Stainless Steel |
| Nut |
Stainless Steel |
| Operating Temperature |
-25°C to +70°C (-13°F to +158°F) |
| Storage Temperature |
-25°C to +70°C (-13°F to +158°F) |
