| Series |
620 |
| Certifications |
RoHS, IK10, IP67 |
| Status |
Active |
| Mounting Hole Size |
0.323" (8.2mm) |
| Output |
TriColor |
| Emitted Color |
Red / Green / Blue |
| LED Position |
Internal |
| Lens Style |
Flat |
| Lens Color |
Non-Tinted, Non-Diffused |
| Voltage |
24 VDC |
| Resistor |
Internal Resistor Included |
| Mounting Method |
Nut/Washer |
| Max Panel Thickness |
.394" (10.0mm) |
| Mounting Torque |
8 |
| Mounting Torque Unit of Measure |
lb-in |
| Polarity Sensitive |
Yes |
| Typical Current (mA) |
15 |
| Typical Intensity (mcd) |
1000 |
| Typical Intensity Color 2 (mcd) |
1500 |
| Typical Intensity Color 3 (mcd) |
700 |
| Termination |
6" Wire Leads |
| Housing Material |
Stainless Steel |
| Nut |
Stainless Steel |
| Operating Temperature |
-40°C to +70°C (-40°F to +158°F) |
| Storage Temperature |
-40°C to +70°C (-40°F to +158°F) |
