Specifications
Specifications
| Series | 612 |
| Certifications | RoHS |
| Status | Active |
| Mounting Hole Size | 0.492" (12.5mm) |
| Output | Single Color |
| Emitted Color | Yellow |
| LED Position | Internal |
| Lens Style | Raised Flat |
| Lens Color | Tinted, Diffused |
| Voltage | 12 VDC |
| Resistor | Internal Resistor Included |
| Mounting Method | Nut/Washer |
| Termination | Solder Terminals |
| Housing Material | Polycarbonate |
| Lock Washer | White Nickel |
| Nut | White Nickel |
| Operating Temperature | -25°C to +85°C (-13°F to +185°F) |
| Storage Temperature | -25°C to +100°C (-13°F to +212°F) |
| Datasheet | Dialight_PMI_data_612_Nov2021.pdf |
| Selector Guide/Catalog | Dialight_Panel_Mount_Indicator_Catalog.pdf |
