Specifications
Specifications
| Series | 605 |
| Certifications | RoHS |
| Status | Active |
| Mounting Hole Size | 0.205" (5.2mm) |
| Output | Single Color |
| Emitted Color | Red |
| LED Position | Protruding |
| Lens Color | Tinted, Diffused |
| Voltage | 2 VDC |
| Resistor | External Resistor Required |
| Mounting Method | Nut/Washer |
| Max Panel Thickness | .138" (3.50mm) |
| Mounting Torque | 0.362 |
| Mounting Torque Unit of Measure | lb-ft |
| Typical Current (mA) | 15 |
| Typical Intensity (mcd) | 38 |
| Termination Finish | Nickel Plated |
| Housing Material | Metal |
| Housing Finish | Chrome Plated |
| Lock Washer | White Nickel |
| Nut | White Nickel |
| Datasheet | Dialight_datasheet_605_5mm.pdf |
| Selector Guide/Catalog | Dialight_Panel_Mount_Indicator_Catalog.pdf |
| Request Compliance Documentation | Request Compliance Documentation |
| C-Drawing | C18646.pdf |
