Specifications
Specifications
| Series | 521 |
| Status | Active |
| Lens Size (mm) | 5.0 |
| Lens Shape | Round |
| Output | Single Color |
| Emitted Color | White |
| Intensity (mcd) COLOR 1 Typ | 1900 |
| Forward Voltage (vdc) - Typ | 3.5 |
| Viewing Angle | 30 |
| Continuous Forward Current (mA) | 30 |
| Peak Forward Current (mA) | 100 |
| Certifications | RoHS |
| Lens Color | Non-Tinted, Non-Diffused |
| Test Current | 20 mA |
| Power Dissipation (mW) COLOR 1 | 111 |
| Reverse Voltage (V) | 5 |
| Operating Temperature | -40°C to +80°C (-40°F to +176°F) |
| Storage Temperature | -40°C to +100°C (-40F to +212°F) |
| Request Compliance Documentation | Request Compliance Documentation |
| C-Drawing | C17600.pdf |
