Specifications
Specifications
| Series | IR |
| Status | Active |
| Package | PLCC-2 |
| Dimension (mm): Length | 2.8 |
| Dimension (mm): Width | 1.2 |
| Dimension (mm): Height | 0.8 |
| Mounting Orientation | Side |
| Emitted Color | IR Non-Visible |
| Lens Color | Non-Tinted, Non-Diffused |
| Packaging Option | 7" Reel |
| Quantity (per reel/sample) | 2000 |
| Viewing Angle | 120 |
| Test Current | 100 mA |
| Peak Wavelength (nm) COLOR 1 | 940 |
| Forward Voltage (vdc) - Typ | 1.5 |
| Forward Voltage (vdc) - Max | 2.1 |
| Reverse Current Intensity (uA) | 100 |
| Forward Voltage (vdc) - Min | 1.3 |
| Continuous Forward Current (mA) | 100 |
| Peak Forward Current (mA) | 1000 |
| Reverse Voltage (V) | 5 |
| Operating Temperature Max | +85°C (+185°F) |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Storage Temperature | -40°C to +100°C (-40F to +212°F) |
| Solder Max Time/Temp °C | 10 sec @ 260 °C |
| Radiant Intensity Min | 10 |
| Radiant Intensity Typ | 13 |
| Radiant Intensity Max | 17.5 |
