| Series |
599 |
| Certifications |
RoHS |
| Status |
Active |
| Package |
1206 |
| Dimension (mm): Length |
3.2 |
| Dimension (mm): Width |
1.6 |
| Dimension (mm): Height |
0.7 |
| Mounting Orientation |
Top |
| Output |
Single Color |
| Emitted Color |
Red-Orange |
| Die 1 |
AlInGaP |
| Packaging Option |
7" Reel |
| Quantity (per reel/sample) |
4000 |
| Viewing Angle |
140 |
| Test Current |
20 mA |
| Dominant Wavelength (nm) COLOR 1 TypS |
625 |
| Intensity (mcd) COLOR 1 Min |
53 |
| Intensity (mcd) COLOR 1 Typ |
90 |
| Forward Voltage (vdc) - Typ |
2.1 |
| Forward Voltage (vdc) - Max |
2.5 |
| Operating Temperature Max |
+100°C (+212°F) |
| Operating Temperature |
-40°C to +100°C (-40F to +212°F) |
| Storage Temperature |
-40°C to +100°C (-40F to +212°F) |
