| Series |
599 |
| Certifications |
RoHS |
| Status |
Active |
| Package |
0603 |
| Dimension (mm): Length |
1.6 |
| Dimension (mm): Width |
0.8 |
| Dimension (mm): Height |
0.6 |
| Mounting Orientation |
Top |
| Output |
BiColor |
| Emitted Color |
Yellow |
| Emitted Color 2 |
Green |
| Die 1 |
AlGaInP |
| Die 2 |
InGaN |
| Lens Color |
Non-Tinted, Non-Diffused |
| Packaging Option |
7" Reel |
| Quantity (per reel/sample) |
4000 |
| Viewing Angle |
120 |
| Test Current |
20 mA |
| Peak Wavelength (nm) COLOR 1 |
593 |
| Peak Wavelength (nm) COLOR 2 |
540 |
| Intensity (mcd) COLOR 1 Min |
112 |
| Intensity (mcd) COLOR 1 Max |
321 |
| Forward Voltage (vdc) - Max |
2.4 |
| Forward Voltage (vdc) COLOR 2 Max |
3.7 |
| Reverse Current Intensity (uA) |
10 |
| Power Dissipation (mW) COLOR 1 |
72 |
| Power Dissipation (mW) COLOR 2 |
111 |
| Intensity (mcd) COLOR 2 Min |
417 |
| Forward Voltage (vdc) - Min |
1.8 |
| Forward Voltage (vdc) COLOR 2 Min |
2.8 |
| Continuous Forward Current (mA) |
30 |
| Peak Forward Current (mA) |
125 |
| Reverse Voltage (V) |
5 |
| Operating Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Solder Max Time/Temp °C |
10 sec @ 260 °C |
