| Series |
597 |
| Certifications |
RoHS |
| Status |
Active |
| Package |
1209 |
| Dimension (mm): Length |
3.2 |
| Dimension (mm): Width |
2.4 |
| Dimension (mm): Height |
2.38 |
| Mounting Orientation |
Top |
| Features |
with Lens |
| Output |
Single Color |
| Emitted Color |
Yellow |
| Die 1 |
AlInGaP |
| Packaging Option |
7" Reel |
| Quantity (per reel/sample) |
1500 |
| Viewing Angle |
25 |
| Test Current |
20 mA |
| Dominant Wavelength (nm) COLOR 1 TypS |
590 |
| Intensity (mcd) COLOR 1 Min |
450 |
| Intensity (mcd) COLOR 1 Typ |
710 |
| Intensity (mcd) COLOR 1 Max |
1800 |
| Forward Voltage (vdc) - Typ |
2 |
| Forward Voltage (vdc) - Max |
2.4 |
| Operating Temperature Max |
+85°C (+185°F) |
| Operating Temperature |
-55°C to +85°C (-67°F to +185°F) |
| Storage Temperature |
-55°C to +85°C (-67°F to +185°F) |
