| Series |
597 |
| Certifications |
RoHS |
| Status |
EOL - Not for New Designs |
| Package |
1208 |
| Dimension (mm): Length |
3.0 |
| Dimension (mm): Width |
2.0 |
| Dimension (mm): Height |
1.0 |
| Mounting Orientation |
Right Angle |
| Output |
BiColor |
| Emitted Color |
Red |
| Emitted Color 2 |
Yellow |
| Die 1 |
AlInGaP |
| Die 2 |
AlInGaP |
| Lens Color |
Non-Tinted, Non-Diffused |
| Packaging Option |
7" Reel |
| Quantity (per reel/sample) |
2500 |
| Viewing Angle |
130 |
| Test Current |
20 mA |
| Peak Wavelength (nm) COLOR 1 |
693 |
| Peak Wavelength (nm) COLOR 2 |
593 |
| Dominant Wavelength (nm) COLOR 1 Typ |
638 |
| Dominant Wavelength (nm) COLOR 2 Typ |
595 |
| Intensity (mcd) COLOR 1 Min |
40 |
| Intensity (mcd) COLOR 1 Max |
112 |
| Forward Voltage (vdc) - Max |
2.4 |
| Forward Voltage (vdc) COLOR 2 Max |
2.4 |
| Power Dissipation (mW) COLOR 1 |
62 |
| Intensity (mcd) COLOR 2 Min |
45 |
| Forward Voltage (vdc) - Min |
1.6 |
| Forward Voltage (vdc) COLOR 2 Min |
1.6 |
| Continuous Forward Current (mA) |
25 |
| Peak Forward Current (mA) |
60 |
| Reverse Voltage (V) |
5 |
| Operating Temperature Max |
+85°C (+185°F) |
| Operating Temperature |
-30°C to +85°C (-22°F to +185°F) |
| Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Replacement P/N |
5988560207F |
