| Series |
597 |
| Certifications |
RoHS |
| Status |
Active |
| Package |
1206 |
| Dimension (mm): Length |
3.2 |
| Dimension (mm): Width |
1.6 |
| Dimension (mm): Height |
1.1 |
| Mounting Orientation |
Reverse Mount |
| Output |
Single Color |
| Emitted Color |
Green |
| Die 1 |
InGaN |
| Lens Color |
Non-Tinted, Non-Diffused |
| Packaging Option |
7" Reel |
| Quantity (per reel/sample) |
3000 |
| Viewing Angle |
70 |
| Test Current |
20 mA |
| Peak Wavelength (nm) COLOR 1 |
530 |
| Dominant Wavelength (nm) COLOR 1 Typ |
525 |
| Dominant Wavelength (nm) COLOR 1 TypS |
525 |
| Intensity (mcd) COLOR 1 Min |
280 |
| Intensity (mcd) COLOR 1 Max |
1120 |
| Forward Voltage (vdc) - Typ |
3 |
| Forward Voltage (vdc) - Max |
3.8 |
| Reverse Current Intensity (uA) |
100 |
| Power Dissipation (mW) COLOR 1 |
76 |
| Forward Voltage (vdc) - Min |
2.8 |
| Continuous Forward Current (mA) |
20 |
| Peak Forward Current (mA) |
100 |
| Derating mA/°C |
.25/25°C |
| Reverse Voltage (V) |
5 |
| Operating Temperature Max |
+85°C (+185°F) |
| Operating Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Storage Temperature |
-40°C to +100°C (-40F to +212°F) |
