| Series |
597 |
| Certifications |
RoHS |
| Status |
Active |
| Package |
0805 |
| Dimension (mm): Length |
2.0 |
| Dimension (mm): Width |
1.25 |
| Dimension (mm): Height |
0.8 |
| Mounting Orientation |
Top |
| Features |
Reflector Cup |
| Output |
Single Color |
| Emitted Color |
Yellow-Green |
| Die 1 |
AlInGaP |
| Lens Color |
Non-Tinted, Non-Diffused |
| Packaging Option |
7" Reel |
| Quantity (per reel/sample) |
4000 |
| Viewing Angle |
116 |
| Test Current |
20 mA |
| Dominant Wavelength (nm) COLOR 1 Typ |
572 |
| Dominant Wavelength (nm) COLOR 1 TypS |
572 |
| Intensity (mcd) COLOR 1 Min |
25 |
| Intensity (mcd) COLOR 1 Typ |
45 |
| Forward Voltage (vdc) - Typ |
2.2 |
| Power Dissipation (mW) COLOR 1 |
81 |
| Continuous Forward Current (mA) |
30 |
| Peak Forward Current (mA) |
100 |
| Reverse Voltage (V) |
5 |
| Operating Temperature Max |
+100°C (+212°F) |
| Operating Temperature |
-40°C to +100°C (-40F to +212°F) |
| Storage Temperature |
-40°C to +100°C (-40F to +212°F) |
