594-2804-013F

594 Prism® SMD 1.6mm Rnd W 2mA 13" Reel

  • Specifications

    Specifications
    Series 594
    Certifications RoHS
    Status Active
    Lens Size (mm) 1.6
    Lens Shape Round
    Lens Material Silicone
    Levels Single Level
    Output Single Color
    Position 1 Emitted Color White
    Packaging Option 13" Reel
    Quantity (per reel/sample) 1600
    Test Current Pos 1 2 mA
    Typ Dominant Wavelength - Pos 1 (nm) X = 0.33 / Y = 0.33
    Typ Intensity - Pos 1 (mcd) 5
    Typ Fwd Voltage - Pos 1 2.75
    Max Fwd Voltage - Pos 1 3.1
    Viewing Angle 120
    Forward Current - Pos 1 (mA) 20
    Peak Fwd Current - Pos 1 (mA) 200
    Electrostatic Discharge - Pos 1 (V) 2000
    Operating Temperature -40°C to +100°C (-40F to +212°F)
    Storage Temperature -40°C to +100°C (-40F to +212°F)
    Solder Max Time/Temp °C 20 sec @ 245 °C
  • Datasheet Dialight_CBI-Prism_data_594_Mar2020.pdf
    C-Drawing C18409C.pdf
    3D STP File 5942x0x0xxf.stp
