| Series |
593 |
| Certifications |
RoHS |
| Status |
Discontinued - Replacement available |
| Lens Size (mm) |
3.0 |
| Lens Shape |
Round |
| Lens Material |
Silicone |
| Levels |
TriLevel |
| Output |
Mixed |
| Position 1 Emitted Color |
Red / Green |
| Position 2 Emitted Color |
Yellow / Green |
| Position 3 Emitted Color |
Blue |
| Packaging Option |
13" Reel |
| Quantity (per reel/sample) |
150 |
| Test Current Pos 1 |
2 mA |
| Test Current Pos 2 |
2 mA |
| Test Current Pos 3 |
10 mA |
| Typ Dominant Wavelength - Pos 1 (nm) |
630 / 570 |
| Typ Dominant Wavelength - Pos 2 (nm) |
587 / 570 |
| Typ Dominant Wavelength - Pos 3 (nm) |
471 |
| Typ Intensity - Pos 1 (mcd) |
11/6 |
| Typ Intensity - Pos 2 (mcd) |
13/6 |
| Typ Intensity - Pos 3 (mcd) |
10 |
| Typ Fwd Voltage - Pos 1 |
1.8 / 1.8 |
| Typ Fwd Voltage - Pos 2 |
1.8 / 1.8 |
| Typ Fwd Voltage - Pos 3 |
3.1 |
| Max Fwd Voltage - Pos 1 |
2.2 / 2.2 |
| Max Fwd Voltage - Pos 2 |
2.2 / 2.2 |
| Max Fwd Voltage - Pos 3 |
3.7 |
| Power Dissipation - Pos 3 (mW) |
80 |
| Forward Current - Pos 1 (mA) |
15 |
| Forward Current - Pos 2 (mA) |
15 |
| Forward Current - Pos 3 (mA) |
20 |
| Peak Fwd Current - Pos 1 (mA) |
100 |
| Peak Fwd Current - Pos 2 (mA) |
100 |
| Peak Fwd Current - Pos 3 (mA) |
200 |
| Electrostatic Discharge - Pos 1 (V) |
2000 |
| Electrostatic Discharge - Pos 3 (V) |
2000 |
| Operating Temperature |
-40°C to +100°C (-40F to +212°F) |
| Storage Temperature |
-40°C to +100°C (-40F to +212°F) |
| Solder Max Time/Temp °C |
5 sec @ 240 °C |
