| Series |
593 |
| Certifications |
RoHS |
| Status |
Active |
| Lens Size (mm) |
3.0 |
| Lens Shape |
Round |
| Lens Material |
Silicone |
| Levels |
TriLevel |
| Output |
TriColor |
| Position 1 Emitted Color |
Green |
| Position 2 Emitted Color |
Yellow |
| Position 3 Emitted Color |
Red |
| Packaging Option |
13" Reel |
| Quantity (per reel/sample) |
150 |
| Test Current Pos 1 |
20 mA |
| Test Current Pos 2 |
20 mA Int / 10 mA Voltage |
| Test Current Pos 3 |
10 mA Int / 20 mA Voltage |
| Typ Dominant Wavelength - Pos 1 (nm) |
525 |
| Typ Dominant Wavelength - Pos 2 (nm) |
587 |
| Typ Dominant Wavelength - Pos 3 (nm) |
640 |
| Min Dominant Wavelength - Pos 2 (nm) |
580 |
| Max Dominant Wavelength - Pos 2 (nm) |
595 |
| Typ Intensity - Pos 1 (mcd) |
213 |
| Typ Intensity - Pos 2 (mcd) |
36 |
| Typ Intensity - Pos 3 (mcd) |
41 |
| Typ Fwd Voltage - Pos 1 |
3.7 |
| Typ Fwd Voltage - Pos 2 |
2 |
| Typ Fwd Voltage - Pos 3 |
1.85 |
| Max Fwd Voltage - Pos 1 |
4.3 |
| Max Fwd Voltage - Pos 2 |
2 |
| Max Fwd Voltage - Pos 3 |
2.5 |
