| Series |
593 |
| Certifications |
RoHS |
| Status |
Active |
| Lens Size (mm) |
3.0 |
| Lens Shape |
Round |
| Lens Material |
Silicone |
| Levels |
TriLevel |
| Position 1 Emitted Color |
Green |
| Position 2 Emitted Color |
Blue |
| Position 3 Emitted Color |
Yellow |
| Packaging Option |
13" Reel |
| Quantity (per reel/sample) |
150 |
| Test Current Pos 1 |
20 mA |
| Test Current Pos 2 |
20 mA |
| Test Current Pos 3 |
20 mA |
| Typ Dominant Wavelength - Pos 1 (nm) |
525 |
| Typ Dominant Wavelength - Pos 2 (nm) |
470 |
| Typ Dominant Wavelength - Pos 3 (nm) |
587 |
| Typ Intensity - Pos 1 (mcd) |
400 |
| Typ Intensity - Pos 2 (mcd) |
100 |
| Typ Intensity - Pos 3 (mcd) |
130 |
| Min Fwd Voltage - Pos 1 |
2.8 |
| Min Fwd Voltage - Pos 2 |
2.8 |
| Min Fwd Voltage - Pos 3 |
1.9 |
| Max Fwd Voltage - Pos 1 |
3.5 |
| Max Fwd Voltage - Pos 2 |
3.5 |
| Max Fwd Voltage - Pos 3 |
2.4 |
| Forward Current - Pos 1 (mA) |
30 |
| Forward Current - Pos 2 (mA) |
30 |
| Forward Current - Pos 3 (mA) |
30 |
| Peak Fwd Current - Pos 1 (mA) |
100 |
| Peak Fwd Current - Pos 2 (mA) |
100 |
| Peak Fwd Current - Pos 3 (mA) |
200 |
| Operating Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Storage Temperature |
-40°C to +100°C (-40F to +212°F) |
| Solder Max Time/Temp °C |
10 sec @ 260 °C |
