| Series |
592 |
| Certifications |
RoHS |
| Status |
Active |
| Lens Size (mm) |
3.0 |
| Lens Shape |
Round |
| Lens Material |
Silicone |
| Levels |
BiLevel |
| Output |
Single Color |
| Position 1 Emitted Color |
Green |
| Position 2 Emitted Color |
Red |
| Packaging Option |
13" Reel |
| Quantity (per reel/sample) |
300 |
| Test Current Pos 1 |
10 mA Int / 20 mA Voltage |
| Test Current Pos 2 |
10 mA Int / 20 mA Voltage |
| Typ Dominant Wavelength - Pos 1 (nm) |
570 |
| Typ Dominant Wavelength - Pos 2 (nm) |
633 |
| Typ Intensity - Pos 1 (mcd) |
18 |
| Typ Intensity - Pos 2 (mcd) |
12 |
| Typ Fwd Voltage - Pos 1 |
2 |
| Typ Fwd Voltage - Pos 2 |
2 |
| Max Fwd Voltage - Pos 1 |
2.4 |
| Max Fwd Voltage - Pos 2 |
2.3 |
| Forward Current - Pos 1 (mA) |
30 |
| Forward Current - Pos 2 (mA) |
30 |
| Peak Fwd Current - Pos 1 (mA) |
1000 |
| Peak Fwd Current - Pos 2 (mA) |
1000 |
| Electrostatic Discharge - Pos 1 (V) |
2000 |
| Electrostatic Discharge - Pos 2 (V) |
2000 |
| Operating Temperature |
-40°C to +100°C (-40F to +212°F) |
| Storage Temperature |
-40°C to +100°C (-40F to +212°F) |
| Solder Max Time/Temp °C |
5 sec @ 260 °C |
