| Series |
592 |
| Certifications |
RoHS |
| Status |
Active |
| Lens Size (mm) |
3.0 |
| Lens Shape |
Round |
| Lens Material |
Silicone |
| Levels |
BiLevel |
| Output |
BiColor |
| Position 1 Emitted Color |
Yellow / Green |
| Position 2 Emitted Color |
Yellow / Green |
| Packaging Option |
13" Reel |
| Quantity (per reel/sample) |
300 |
| Test Current Pos 1 |
20 mA |
| Test Current Pos 2 |
20 mA |
| Typ Dominant Wavelength - Pos 1 (nm) |
590/520 |
| Typ Dominant Wavelength - Pos 2 (nm) |
590/520 |
| Typ Intensity - Pos 1 (mcd) |
145/245 |
| Typ Intensity - Pos 2 (mcd) |
145/245 |
| Min Fwd Voltage - Pos 1 |
1.8/2.8 |
| Min Fwd Voltage - Pos 2 |
1.8/2.8 |
| Max Fwd Voltage - Pos 1 |
2.4/3.4 |
| Max Fwd Voltage - Pos 2 |
2.4/3.4 |
| Operating Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Storage Temperature |
-40°C to +100°C (-40F to +212°F) |
| Solder Max Time/Temp °C |
10 sec @ 260 °C |
