592-3030-313F

592 Prism® SMD 3mm BiLevel Rnd BiColor R/G,R/G 13" Reel

  • Specifications

    Specifications
    Series 592
    Certifications RoHS
    Status Active
    Lens Size (mm) 3.0
    Lens Shape Round
    Lens Material Silicone
    Levels BiLevel
    Output BiColor
    Position 1 Emitted Color Red / Green
    Position 2 Emitted Color Red / Green
    Packaging Option 13" Reel
    Quantity (per reel/sample) 300
    Test Current Pos 1 10 mA
    Test Current Pos 2 10 mA
    Typ Dominant Wavelength - Pos 1 (nm) 628 / 570
    Typ Dominant Wavelength - Pos 2 (nm) 628 / 570
    Typ Intensity - Pos 1 (mcd) 11/5
    Typ Intensity - Pos 2 (mcd) 11/5
    Typ Fwd Voltage - Pos 1 2 / 2.0
    Typ Fwd Voltage - Pos 2 2 / 2.0
    Max Fwd Voltage - Pos 1 2.5 / 2.5
    Max Fwd Voltage - Pos 2 2.5 / 2.5
    Power Dissipation - Pos 1 (mW) 95 / 95
    Power Dissipation - Pos 2 (mW) 95 / 95
    Forward Current - Pos 1 (mA) 30
    Forward Current - Pos 2 (mA) 30
    Peak Fwd Current - Pos 1 (mA) 500
    Peak Fwd Current - Pos 2 (mA) 500
    Operating Temperature -40°C to +100°C (-40F to +212°F)
    Storage Temperature -40°C to +100°C (-40F to +212°F)
    Solder Max Time/Temp °C 20 sec @ 255 °C
  • C-Drawing C17882.pdf
    3D STP File 592-PRISM_BI_TRI_COLOR.stp
