591-2801-113NF

591 Prism® SMD 3mm Sq W 13" Reel

  • Specifications

    Specifications
    Series 591
    Certifications RoHS
    Status Active
    Lens Size (mm) 3.0
    Lens Shape Square
    Lens Material Silicone
    Levels Single Level
    Output Single Color
    Position 1 Emitted Color White
    Packaging Option 13" Reel
    Quantity (per reel/sample) 1600
    Test Current Pos 1 10 mA
    Chromaticity Coordinates (xy) or CCT (K) x=0.281 / y=0.247
    Typ Intensity - Pos 1 (mcd) 230
    Typ Fwd Voltage - Pos 1 2.7
    Max Fwd Voltage - Pos 1 3.1
    Viewing Angle 40
    Operating Temperature -40°C to +100°C (-40F to +212°F)
    Storage Temperature -40°C to +100°C (-40F to +212°F)
    Solder Max Time/Temp °C 5 sec @ 260 °C
  • C-Drawing C18498.pdf
    3D STP File 591-PRISM_square_lens.stp
