591-3001-013F

591 Prism® SMD 3mm Rnd BiColor R/G 2mA 13" Reel

  • Specifications

    Specifications
    Series 591
    Certifications RoHS
    Status Active
    Lens Size (mm) 3.0
    Lens Shape Round
    Lens Material Silicone
    Levels Single Level
    Output BiColor
    Position 1 Emitted Color Red / Green
    Packaging Option 13" Reel
    Quantity (per reel/sample) 1600
    Test Current Pos 1 2 mA
    Typ Dominant Wavelength - Pos 1 (nm) 630 / 570
    Typ Intensity - Pos 1 (mcd) 17/11 @10 mA
    Typ Fwd Voltage - Pos 1 1.7 / 1.7
    Max Fwd Voltage - Pos 1 2.2 / 2.2
    Viewing Angle 40
    Power Dissipation - Pos 1 (mW) 0 / 0
    Forward Current - Pos 1 (mA) 15
    Peak Fwd Current - Pos 1 (mA) 100
    Electrostatic Discharge - Pos 1 (V) 2000
    Operating Temperature -40°C to +100°C (-40F to +212°F)
    Storage Temperature -40°C to +100°C (-40F to +212°F)
    Solder Max Time/Temp °C 20 sec @ 240 °C
  • C-Drawing C17245.pdf
    3D STP File 591-PRISM_round_lens.stp
