Specifications
Specifications
| Series | 586 |
| Certifications | RoHS |
| Status | Active |
| Bulb Base Size | T-1 3/4 Midget Flange |
| Emitted Color | Blue |
| Configuration | Single Chip |
| Voltage | 14 VDC |
| Peak Wavelength (nm) | 467 |
| Typical Current (mA) | 10 |
| Typical Intensity (mcd) | 210 |
| Polarity | Polarized |
| Operating Temperature | -40°C to +80°C (-40°F to +176°F) |
| Storage Temperature | -40°C to +100°C (-40F to +212°F) |
| Selector Guide/Catalog | Dialight_Panel_Mount_Indicator_Catalog.pdf |
| Request Compliance Documentation | Request Compliance Documentation |
