| Series |
557 |
| Certifications |
RoHS, Watertight to Mil-L-3661B Spec |
| Status |
Active |
| Features |
Watertight |
| Mounting Hole Size |
0.687" (17.45mm) |
| Output |
Single Color |
| Emitted Color |
Blue |
| LED Position |
Internal |
| Lens Style |
Flat |
| Lens Color |
Non-Tinted, Diffused |
| Voltage |
12 VDC |
| Mounting Method |
Nut/Washer |
| Max Panel Thickness |
.156" (3.96mm) |
| Mounting Torque |
15 |
| Mounting Torque Unit of Measure |
lb-in |
| Typical Current (mA) |
16 |
| Typical Intensity (mcd) |
1200 |
| Termination |
5.5" Wire Leads |
| Lead Wire Gauge |
24 AWG |
| Housing Material |
Polycarbonate |
| Lens Material |
Transparent Polycarbonate (UL 94V-0) |
| Lock Washer |
White Nickel |
| Nut |
White Nickel |
| Operating Temperature |
-25°C to +85°C (-13°F to +185°F) |
| Storage Temperature |
-30°C to +100°C (-22°F to +212°F) |
| Polarity Sensitive |
Yes |
