| Series |
555 |
| Certifications |
RoHS |
| Status |
Active |
| Lens Size (mm) |
2.0 |
| Lens Shape |
Round |
| Mounting Orientation |
Right Angle |
| LED Position |
Protruding |
| Overall Output |
Single Color |
| Emitted Color |
Green |
| Total #LEDs |
1 |
| LED Color Configuration |
G |
| Lens Color |
Tinted, Non-Diffused |
| Viewing Angle |
35 |
| Features |
ESD Packaging |
| Resistor |
None |
| Test Current |
20 mA |
| Intensity (mcd) |
25 |
| Forward Voltage |
2.1 |
| Forward Voltage - Max |
2.7 |
| Peak Wavelength (nm) |
565 |
| Dominant Wavelength (nm) |
569 |
| Reverse Current Intensity (uA) |
100 |
| Continuous Forward Current (mA) |
30 |
| Derating mA/°C |
0.5 from 50°C |
| Operating Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Storage Temperature |
-55°C to +100°C (-67°F to +212°F) |
| Solder Max Time/Temp °C |
5 sec @ 260 °C |
