| Series |
550 |
| Certifications |
RoHS |
| Status |
Active |
| Lens Size (mm) |
5.0 |
| Lens Shape |
Round |
| Housing Configuration |
1 x 1 |
| Mounting Orientation |
Right Angle |
| LED Position |
Protruding |
| Housing Form |
block |
| Overall Output |
Single Color |
| Emitted Color |
Red |
| Lens Color |
Non-Tinted, Non-Diffused |
| Features |
Reverse Polarity |
| Polarity |
Cathode Left |
| Power Dissipation (mW) |
135 |
| Continuous Forward Current (mA) |
30 |
| Peak Forward Current (mA) |
500 |
| Derating mA/°C |
0.4mA FROM 25°C |
| Operating Temperature |
-55°C to +100°C (-67°F to +212°F) |
| Storage Temperature |
-55°C to +100°C (-67°F to +212°F) |
| Solder Max Time/Temp °C |
5 sec @ 260 °C |
