Specifications
Specifications
| Series | 521 |
| Status | Active |
| Lens Size (mm) | 5.0 |
| Lens Shape | Round |
| Output | Single Color |
| Emitted Color | Green |
| Peak Wavelength (nm) COLOR 1 | 565 |
| Intensity (mcd) COLOR 1 Typ | 1 |
| Forward Voltage (vdc) - Typ | 1.8 |
| Forward Voltage (vdc) - Max | 2.2 |
| Viewing Angle | 50 |
| Continuous Forward Current (mA) | 7 |
| Peak Forward Current (mA) | 500 |
| Certifications | RoHS |
| Lens Color | Tinted, Diffused |
| Test Current | 2 mA |
| Power Dissipation (mW) COLOR 1 | 16 |
| Reverse Voltage (V) | 5 |
| Operating Temperature | -20°C to +100°C (-4°F to +212°F) |
| Request Compliance Documentation | Request Compliance Documentation |
| C-Drawing | C17806.pdf |
