| Series |
521 |
| Status |
Active |
| Lens Size (mm) |
3.0 |
| Output |
BiColor |
| Emitted Color |
Red |
| Emitted Color 2 |
Green |
| Peak Wavelength (nm) COLOR 1 |
630 |
| Peak Wavelength (nm) COLOR 2 |
565 |
| Dominant Wavelength (nm) COLOR 1 Typ |
621 |
| Dominant Wavelength (nm) COLOR 2 Typ |
569 |
| Intensity (mcd) COLOR 1 Typ |
13 |
| Forward Voltage (vdc) - Typ |
2 |
| Viewing Angle |
100 |
| Continuous Forward Current (mA) |
30 |
| Peak Forward Current (mA) |
90 |
| Certifications |
RoHS |
| Lens Shape |
Round |
| Lens Color |
Non-Tinted, Diffused |
| Test Current |
2 mA Int / 20 mA Voltage |
| Power Dissipation (mW) COLOR 1 |
100 |
| Derating mA/°C |
0.4 FROM 50°C |
| Reverse Voltage (V) |
5 |
| Operating Temperature |
-30°C to +80°C (-22°F to +176°F) |
| Storage Temperature |
-40°C to +100°C (-40F to +212°F) |
