| Series |
521 |
| Status |
Active |
| Lens Size (mm) |
3.0 |
| Output |
BiColor |
| Emitted Color |
Green |
| Emitted Color 2 |
Blue |
| Peak Wavelength (nm) COLOR 1 |
565 |
| Peak Wavelength (nm) COLOR 2 |
428 |
| Dominant Wavelength (nm) COLOR 1 Typ |
569 |
| Dominant Wavelength (nm) COLOR 2 Typ |
465 |
| Intensity (mcd) COLOR 1 Typ |
14 |
| Intensity (mcd) COLOR 2 Typ |
8.5 |
| Forward Voltage (vdc) - Typ |
2.1 |
| Forward Voltage (vdc) - Max |
2.5 |
| Forward Voltage (vdc) COLOR 2 Typ |
4 |
| Forward Voltage (vdc) COLOR 2 Max |
4.8 |
| Viewing Angle |
60 |
| Continuous Forward Current (mA) |
30/20 |
| Peak Forward Current (mA) |
90/50 |
| Certifications |
RoHS |
| Lens Shape |
Round |
| Lens Color |
Non-Tinted, Diffused |
| Test Current |
20 mA |
| Power Dissipation (mW) COLOR 1 |
75 |
| Power Dissipation (mW) COLOR 2 |
100 |
| Derating mA/°C |
Green: 0.4 FROM 50°C / Blue: 0.3 FROM 30°C |
| Operating Temperature |
-20°C to +80°C (-4°F to +176°F) |
| Storage Temperature |
-30°C to +100°C (-22°F to +212°F) |
