| Series |
521 |
| Status |
Active |
| Lens Size (mm) |
3.0 |
| Lens Shape |
Round |
| Output |
Single Color |
| Emitted Color |
Yellow |
| Peak Wavelength (nm) COLOR 1 |
591 |
| Dominant Wavelength (nm) COLOR 1 Typ |
587 |
| Intensity (mcd) COLOR 1 Typ |
5 |
| Forward Voltage (vdc) - Typ |
1.8 |
| Forward Voltage (vdc) - Max |
2.4 |
| Viewing Angle |
60 |
| Continuous Forward Current (mA) |
7 |
| Peak Forward Current (mA) |
500 |
| Certifications |
RoHS |
| Lens Color |
Tinted, Diffused |
| Test Current |
2 mA |
| Reverse Current Intensity (uA) |
10 |
| Power Dissipation (mW) COLOR 1 |
20 |
| Reverse Voltage (V) |
5 |
| Operating Temperature |
-55°C to +100°C (-67°F to +212°F) |
| Storage Temperature |
-55°C to +100°C (-67°F to +212°F) |
