| Series |
249 |
| Certifications |
RoHS, UL |
| Status |
Active - Data Coming Soon - Please contact us for specifications. |
| Mounting Hole Size |
0.375" (9.53mm) |
| Output |
Single Color |
| Emitted Color |
Yellow |
| LED Position |
Protruding |
| Lens Style |
Stovepipe |
| Lens Color |
Tinted, Non-Diffused |
| Voltage |
3.6 VDC |
| Resistor |
Internal Resistor Included |
| Mounting Method |
Nut/Washer |
| Max Panel Thickness |
0.312" (7.92mm) |
| Mounting Torque |
8 – 10 |
| Mounting Torque Unit of Measure |
lb-in |
| Typical Current (mA) |
20 |
| Typical Intensity (mcd) |
150 |
| Termination |
Turret |
| Housing Material |
Aluminum |
| Lock Washer |
Phosphor Bronze - White Nickel Plated |
| Nut |
Brass - White Nickel Plated |
| Operating Temperature |
-55°C to +71°C (-67°F to +160°F) |
| Storage Temperature |
-55°C to +71°C (-67°F to +160°F) |
| Housing Finish___housing_finish |
Black Anodized |
