Specifications
Specifications
| Certifications | RoHS |
| Status | Active |
| Lens Size (mm) | 1.8 |
| Output | Single Color |
| Emitted Color | Red |
| Lens Color | Tinted, Diffused |
| Test Current | 20 mA |
| Viewing Angle | 50 |
| Continuous Forward Current (mA) | 30 |
| Peak Forward Current (mA) | 120 |
| Derating mA/°C | 0.4 FROM 40°C |
| Operating Temperature | -55°C to +100°C (-67°F to +212°F) |
| Storage Temperature | -55°C to +100°C (-67°F to +212°F) |
| Solder Max Time/Temp °C | 5 sec @ 260 °C |
| C-Drawing | C17502.pdf |
